Acti 9 – IC2000 – twilight switch – 2…2000 lux
107,000 CFA
Ref CCT15368
Description
| range of product |
Acti 9
|
|
|---|---|---|
| product name |
Acti 9 IC
|
|
| product or component type |
Twilight switch
|
|
| device short name |
IC2000
|
|
| provided equipment |
wall-mounted cell
|
|
| load type |
230 V AC halogen lamp: 2300 W
230 V AC incandescent lamp: 2300 W dual mounted fluorescent tube with conventional ballast: 2300 VA dual mounted fluorescent tube with electronic ballast: 300 VA fluocompact lamp with conventional ballast: 1500 VA non-corrected fluorescent tube with conventional ballast: 2300 VA parallel-corrected fluorescent tube with conventional ballast: 400 VA parallel-corrected mercury and sodium vapour lamps: 400 VA serial-corrected fluorescent tube with conventional ballast: 2300 VA 7 x 11 W fluocompact lamp with electronic ballast 7 x 15 W fluocompact lamp with electronic ballast 7 x 20 W fluocompact lamp with electronic ballast 7 x 23 W fluocompact lamp with electronic ballast 9 x 7 W fluocompact lamp with electronic ballast |
|
| function available |
Cabling test function with a push-button on front face
|
| device application |
Building
|
|
|---|---|---|
| number of channels |
1
|
|
| power consumption in VA |
6 VA
|
|
| [Ue] rated operational voltage |
230 V AC +10 % -15 % at 50/60 Hz
|
|
| maximum switching current |
10 A – 250 V AC pf = 0.6
16 A – 250 V AC pf = 1 |
|
| electrical insulation class |
Class II
|
|
| opening distance |
< 3 mm
|
|
| status LED |
LED (green)threshold reached
LED (red)brightness less than the threshold |
|
| time delay |
>= 60 s on closing
>= 60 s on breaking contact |
|
| 9 mm pitches |
5
|
|
| light intensity adjustment |
2…2000 lux
|
|
| connections – terminals |
2 x 2.5 mm² screwless terminals
|
|
| height |
85 mm
|
|
| width |
45 mm
|
|
| depth |
65 mm
|
|
| net weight |
280 g
|
|
| brightness sensing type |
Analog wall-mounted cell
|
|
| control type |
By brightness detection
|
|
| market segment |
Residential
Small commercial |
|
| compatibility code |
IC2000
|
| ambient air temperature for operation |
-25…50 °C
|
|
|---|---|---|
| IP degree of protection |
IP20 B
|
|
| standards |
EN 60529
EN 60669 |
| Package 1 Weight |
0.299 kg
|
|
|---|---|---|
| Package 1 Height |
0.860 dm
|
|
| Package 1 width |
0.940 dm
|
|
| Package 1 Length |
1.100 dm
|
Additional information
| Brand |
Schneider |
|---|
