Acti 9 – IC2000 – twilight switch – 2…2000 lux

Main
range of product
Acti 9
product name
Acti 9 IC
product or component type
Twilight switch
device short name
IC2000
provided equipment
wall-mounted cell
load type
230 V AC halogen lamp: 2300 W
230 V AC incandescent lamp: 2300 W
dual mounted fluorescent tube with conventional ballast: 2300 VA
dual mounted fluorescent tube with electronic ballast: 300 VA
fluocompact lamp with conventional ballast: 1500 VA
non-corrected fluorescent tube with conventional ballast: 2300 VA
parallel-corrected fluorescent tube with conventional ballast: 400 VA
parallel-corrected mercury and sodium vapour lamps: 400 VA
serial-corrected fluorescent tube with conventional ballast: 2300 VA
7 x 11 W fluocompact lamp with electronic ballast
7 x 15 W fluocompact lamp with electronic ballast
7 x 20 W fluocompact lamp with electronic ballast
7 x 23 W fluocompact lamp with electronic ballast
9 x 7 W fluocompact lamp with electronic ballast
function available
Cabling test function with a push-button on front face
Complementary
device application
Building
number of channels
1
power consumption in VA
6 VA
[Ue] rated operational voltage
230 V AC +10 % -15 % at 50/60 Hz
maximum switching current
10 A – 250 V AC pf = 0.6
16 A – 250 V AC pf = 1
electrical insulation class
Class II
opening distance
< 3 mm
status LED
LED (green)threshold reached
LED (red)brightness less than the threshold
time delay
>= 60 s on closing
>= 60 s on breaking contact
9 mm pitches
5
light intensity adjustment
2…2000 lux
connections – terminals
2 x 2.5 mm² screwless terminals
height
85 mm
width
45 mm
depth
65 mm
net weight
280 g
brightness sensing type
Analog wall-mounted cell
control type
By brightness detection
market segment
Residential
Small commercial
compatibility code
IC2000
Environment
ambient air temperature for operation
-25…50 °C
IP degree of protection
IP20 B
standards
EN 60529
EN 60669
Packing Units
Package 1 Weight
0.299 kg
Package 1 Height
0.860 dm
Package 1 width
0.940 dm
Package 1 Length
1.100 dm
