| Range |
Asfora
|
|
|---|---|---|
| product or component type |
Socket-outlet
|
|
| outlet standard description |
Pin earth
|
|
| outlet poles configuration |
2P + E
|
|
| device presentation |
Mechanism with fixing frame
|
|
| colour tint |
Anthracite
|
|
| type of packing |
Flow-pack
|
| socket number |
1
|
|
|---|---|---|
| device mounting |
Flush
|
|
| power range |
3680 W
|
|
| rated current |
16 A at 250 V AC
|
|
| connections – terminals |
Lift terminals
|
|
| number of cables |
2 cable(s) 2.5 mm²
|
|
| cable stiffness |
Flexible
Rigid Solid stranded |
|
| wire stripping length |
13.0Â mm
|
|
| material |
ABS + PC: central plate
|
|
| surface finish |
Painted
|
|
| conductor material |
Copper
|
|
| fixing mode |
Screws or claws51…69 mm
|
|
| height |
71Â mm
|
|
| width |
71Â mm
|
|
| depth |
42Â mm
|
|
| projecting depth |
10Â mm
|
|
| Quantity per set |
1
|
|
| net weight |
0.069Â kg
|
| standards |
IEC 60884-1
|
|
|---|---|---|
| product certifications |
SEP-BBJ
TSE |
|
| IP degree of protection |
IP20
|
| Unit Type of Package 1 |
PCE
|
|
|---|---|---|
| Number of Units in Package 1 |
1
|
|
| Package 1 Weight |
71.5Â g
|
|
| Package 1 Height |
4.1Â cm
|
|
| Package 1 width |
7.1Â cm
|
|
| Package 1 Length |
7.1Â cm
|
|
| Unit Type of Package 2 |
BB1
|
|
| Number of Units in Package 2 |
10
|
|
| Package 2 Weight |
787.25Â g
|
|
| Package 2 Height |
9.7Â cm
|
|
| Package 2 width |
18.6Â cm
|
|
| Package 2 Length |
27.5Â cm
|
|
| Unit Type of Package 3 |
S04
|
|
| Number of Units in Package 3 |
120
|
|
| Package 3 Weight |
10.008Â kg
|
|
| Package 3 Height |
30Â cm
|
|
| Package 3 width |
40Â cm
|
|
| Package 3 Length |
60Â cm
|
