Circuit breaker EasyPact CVS160B, 25 kA at 415 VAC, 125 A rating thermal magnetic TM-D trip unit, 4P 3d
210,000 CFA
Ref: LV516312
Description
| range of product |
Easypact CVS100…250
|
|
|---|---|---|
| product or component type |
Circuit breaker
|
|
| device short name |
CVS160B
|
|
| device application |
Distribution
|
|
| poles description |
4P
|
|
| protected poles description |
3d
|
|
| neutral position |
Left
|
|
| Earth leakage protection (Vigi add on) |
Without
|
|
| [In] rated current |
160 A at 40 °C
|
|
| breaking capacity code |
B
|
|
| network type |
AC
|
|
| [Icu] Breaking capacity |
40Â kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
25Â kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 20Â kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 |
|
| utilisation category |
Category A
|
|
| trip unit name |
TM-D
|
|
| trip unit technology |
Thermal-magnetic
|
|
| trip unit rating |
125 A at 40 °C
|
|
| protection type |
Short-circuit protection (magnetic)
Overload protection (thermal) |
| network frequency |
50/60 Hz
|
|
|---|---|---|
| control type |
Toggle
|
|
| mounting mode |
Fixed
|
|
| mounting support |
Backplate
|
|
| upside connection |
Front
|
|
| downside connection |
Front
|
|
| connections – terminals |
Screw connection
|
|
| [Uimp] rated impulse withstand voltage |
8Â kV conforming to EN/IEC 60947-2
|
|
| thermal protection adjustment range |
87.5…125 A
|
|
| [Ics] rated service breaking capacity |
15Â kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
25Â kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 40Â kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 |
|
| mechanical durability |
25000Â cycles
|
|
| electrical durability |
12000Â cycles 415 V In conforming to IEC 60947-2
|
|
| connection pitch |
35Â mm
|
|
| contact position indicator |
Yes
|
|
| neutral protection setting |
No protection (3d)
|
|
| long time pick-up adjustment type Ir |
Adjustable
|
|
| long time pick-up adjustment range |
0.7…1 x In
|
|
| long time delay adjustment type |
Fixed
|
|
| instantaneous pick-up adjustment type Ii |
Fixed
|
|
| instantaneous pick-up adjustment range |
1250 A
|
|
| height |
161Â mm
|
|
| width |
140Â mm
|
|
| depth |
86Â mm
|
|
| net weight |
2.3Â kg
|
