Residual current circuit breaker – 2 poles – 63 A – 230 V – class AC 300mA

Technical: neutral position Left device location in system Outgoer [In] rated current 63 A network type AC network

frequency 50/60 Hz [Ue] rated operational voltage 400 V AC 50/60 Hz conforming to IEC 61008 residual current

tripping technology Electromechanical earth-leakage sensitivity 300 mA earth-leakage protection time delay

Instantaneous rated breaking and making capacity Im = 630 A-rated conditional short-circuit current 6 kA 63 A [Ui]

rated insulation voltage 440 V [Uimp] rated impulse withstand voltage 4 kV control type Toggle mounting mode

Fixed mounting support 35 mm symmetrical DIN rail 9 mm pitches 4 height 81 mm width 36 mm depth 76 mm

connections – terminals Tunnel type terminals1…25 mm² flexible Tunnel type terminals1…35 mm² rigid
